Prepper projects: Crafting your own rainwater collection system

By hrseditor // 2024-10-08

Having a rainwater collection system on your homestead is a great idea if you have a home garden. It can also provide you with a backup water source if you are worried about water shortage-related emergencies. (h/t to AskAPrepper.com)

Supplies for a rainwater collection system

To build a rainwater collection system, you will need three high density polyethylene (HDPE) 55-gallon barrels. HDPE barrels are ideal because they will resist UV rays and slow algae growth. Clean the barrels before you get started. If the barrels have a buttress thread, they will require a special adapter to connect to the common ABS fittings. Here is a complete list of needed supplies:

• 3 55-gallon HDPE barrels
• Pipe Thread Sealant
• Buttress thread adapter to 2″ NPT Male (6 pieces)
• 2 in. ABS DWV male adapter (6 pieces)
• 2” ABS long 90-degree elbow (5 pieces) + 2” ABS short 90-degree elbow (1 piece)
• 2” ABS WYE or Tee fitting (1 piece) + 2” x 4” ABS Coupler (1 piece)
• 2” ABS pipe; ABS Cement
• 4”x4” x 8ft Treated lumber (6 pieces) + 2”x4” x 6ft Treated lumber (2 pieces)
• 3.5” x 0.25” Aluminum Angle (16 pieces)
• ¼” Lag Bolts and Washers (Use stainless ones for the feet)
• Flexible downspout (2 pieces) + Extra downspout
• PVC adapters and spigot

Constructing the rainwater collection system

Lay out two lengths of the 4×4 and figure out the spacing so you can still remove the barrels and be able to place a bucket under the spigot. Cut the 4x4s to 23" long and space them 24" apart with the bottom level measuring 16" above the ground. The 4x4s should be running parallel to the barrels that are cut to 27.25" long. (Related: Prepper essentials: Tips for setting up a rainwater collection system.) Since each barrel can hold at least 450 lbs. of water, get a local metal supplier to cut 16 pieces of 3.5"x3.5"x 0.25" aluminum angle at 3.25" long to serve as brackets. Carefully drill six holes in each big enough to fit the ¼” lag bolts. Get four pieces of 0.25" thick stainless steel tread plate measuring 8"x8" and 16 pieces of 2"x2" x 0.125" angle at the metal store to weld up the feet for the system. Doing this will help keep the four posts from sitting in the mud on wet days and provide a better footing for the nearly 1,500 lbs. of maximum water storage. Prevent the barrels from rolling and putting extra stress on the ABS fittings by cutting 12 pieces of 2x4s with a 45-degree bevel on one end at 7.5" long. Add two 2x4s measuring 34" across the top for added rigidity.

Plumbing for the rainwater collection system

Add pipe thread sealant to the DWV and mate it with the buttress adapter. The thread sealant is less permanent and would allow you to tighten the fittings if any leaks formed, or when you need to replace a cracked fitting. Mating these adapters before installing them on the barrels means you won't overtighten or strip any of the threads. Dry fit all of the ABS fittings so you can measure and cut the ABS pipe to length. Clean all the fittings and pipes and glue them together with ABS cement. Follow the manufacturer's installation guidelines. The top fill spout combined with the wye (or tee) fitting allows the barrels to fill up and drain any excess back down the drain spout when it rains. Add a piece of window screen material over the spout to keep out large debris and secure it with a hose clamp. Putting this screen on the very top allows the debris to continually be washed away without having to worry about any filters getting clogged or needing replacement. Cut the aluminum downspout and add the flexible downspout to divert it to your harvesting system. Attach a short piece of downspout with a screw to the overflow of the fill spout to feed it back into the original downspout. If you live in an area with freezing temperatures in the winter, keep in mind that keeping a full system may result in cracked fittings. Drain all but the bottom barrel to avoid having to replace the fittings every year. The flexible downspouts make it easier to reconnect the downspout to the drain and bypass the barrels in the winter.
